HELIX Ci3 FX-UNI.2 - 2-Way Flex-Crossover

HELIX COMPOSE. The perfect speaker for any composition.

Born out of the increasingly demanding challenges of modern automobile technology and the HELIX-typical pursuit of intelligent solutions, we made the progressive redesign of proven universal speaker systems our mission. The result: our innovative HELIX COMPOSE platform that, according to the motto "developed inside the vehicle, for the vehicle", combines classic universal speakers with the advantages of vehicle-specific systems. Innovative materials and the latest technologies paired with smart, practical engineering - the best of both worlds in harmony: high efficiency, fantastic sound quality and enormous dynamics that fit in any vehicle. HELIX COMPOSE – universal speakers evolved.

Overview

Perfectly separated

Our Ci3 FX-UNI.2 crossover is designed for the ideal use with our HELIX Compose i3 components, and thus for the COMPOSE-typical, professional integration into the vehicle It offers a 6-stage tweeter level adjustment with 12 dB slope for optimal adaptation to the installation position as well as an integrated tweeter protection. In addition, no effort was spared in the complex tuning of the crossover for the best possible distribution of the frequency band and a harmonious sound image. Thanks to its compact dimensions, the Ci3 FX-UNI.2 is perfectly suited for installation in tight spaces and is furthermore compatible with our COMPOSE Connect and WireKit technologies for a safe and fool-proof connection according to automotive standards.

COMPOSE Connect

Kiss tinkering and soldering goodbye. Compose Connect is the sophisticated plug-in connection that considerably simplifies car audio installation in conjunction with HELIX COMPOSE components. Proprietary plastic housings into which standard flat plugs and couplings can be snapped, establish an absolutely safe connection in accordance with automotive standards that prevents any polarity reversal.

WireKits – Plug & Play at its best

Our WireKits realize the connection of HELIX COMPOSE crossover to the original wiring harness in the most comfortable way. With manufacturing according to the high standards of the automotive industry, these arrestable adaptor cables meet all requirements for the harsh environmental conditions that installers face in vehicles every day.

Features

• 6-stage tweeter level adjustment for optimized treble adaption to the mounting position
• Integrated tweeter protection
• Extensively fine-tuned with 12 dB slope for tweeter
• COMPOSE Connect – Smart, automotive-grade connectors for fail-safe and secure installation
• Compact dimensions for easy integration
• Designed for optionally available, car-specific WireKits which allow a non-destructive integration
• Compatible with all COMPOSE i3 loudspeakers

Technical Data

Compatibility

Tweeter:

• Ci3 T20FM-TI

Midrange / Midbass / Woofer:

• Ci3 M100FM-S3
• Ci3 W130-S3
• Ci3 W165FM-S3
• Ci3 W165FM-S2
• Ci3 W200FM-S3
• Ci3 W200FM-S2

Scope of delivery

• 2 x Ci3 FX UNI.2
• 2 x COMPOSE Connect Kit
