Premium cars deserve premium sound – and this includes a deep and punchy bass reproduction which the basic speaker setup in Mercedes vehicles doesn't deliver at all. However, the perfect solution is quite simple – the heavy-duty 8” / 200 mm woofers of the UP W8MB-S4 system fit perfectly into the original mounting positions in the bulkhead and provide exactly the right punch that you can feel and which brings music to life.
Especially in combination with one of our DSP amplifiers these subwoofers reveals their full potential in respect of dynamics.

Features

Optimized sound characteristics for Mercedes vehicles for a spectacular sound in combination with significantly increased power handling
Exclusively developed baskets and car-specific connectors for Mercedes vehicles for easiest installation
Perfectly combinable with further MATCH UPGRADE components – e.g. DSP amplifier
Right hand drive version

Technical data

Power RMS / max.	P	100 / 200 Watts
Impedance	Z	1 x 4 Ω
DC resistance	Re	3,6 Ω
Frequency response		25 - 250 Hz
Resonance frequency	Fs	51 Hz
Mechanical Q factor	Qms	7.24
Electrical Q factor	Qes	0.71
Total Q factor	Qts	0.64
Compliance	Cms	276 µm/N
Equivalent air volume	Vas	18 L
Force factor	BI*	7.6 Tm
Efficiency 1 W / 1 m	SPL	88 dB
Cone area	Sd	216 cm²
Moving mass	Mms	35 g
Cone material		Paper cone
Mechanical resistance	Rms	1.6 kg/s
Voice coil diameter	ø	37 mm
Voice coil winding height		16 mm
Max. linear excursion	Xmax	+/- 5 mm

Compatibility

Model	Model type	Series	Model year
C	Convertible Coupe Sedan T-model	A205 C205 W205 S205	ab 2016 ab 2015 From 2014 From 2014

E	Convertible Coupe Sedan T-model	A238 C238 W213 S213	From 2017 From 2017 From 2016 From 2016

GLC	SUV SUV coupe	X253 C253	From 2015 From 2015

S	Sedan	W222	From 2013

Status: May 2019

Scope of delivery

2 x Subwoofer MATCH UP W8MB-S4 right hand drive version
1 x Universal connection cable
1 x Instruction manual
